Radar Level Sensor

Lower cost laser level meter for sale online with digital LCD display. The radar level meter with G1.5/ DN50 connection size for selection, 304/ 306 stainless steel material can be chosen. Digital laser level meter with 0.02m~100m wide range measuring distance. High accuracy radar level gauge is widely used in pharmaceutical production, plastic high-risk areas and the environmental and recycling industries.

Economical price radar level sensor is a non-contact measurement. Measuring range from 0 to 30m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, installation of G1-1/2"A thread or flange. Radar type level transmitter consists of protection head with LCD display, 26 GHz microwave frequency, waterproof connectors, internal radar antenna, horn and installation accessory for measuring various highly corrosive liquids.

High frequency 80 GHz radar level sensor is a non-contact radar type level transmitter that can detect solid powder and liquid materials, available with optional 10m to 60m wide range, 24V DC or 220V AC power supply, 4-20mA/RS485/HART output, 3°/8°/20° beam angle and threaded or stainless steel flanged connection.

Radar level sensor has a frequency range of 120 GHz, it delivers high accuracy of ±3mm and includes IP68-level. The radar level transmitter outputs data via RS485 and supports calibration through Bluetooth/Modbus protocol. It has angle compensation and temperature compensation, operates on a 3.6V or 12V power supply. Applications in river channels, lakes, and front shoals.

Economical price radar level sensor is a non-contact liquid measurement. Measuring range from 0 to 20m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, installation of DN80, DN100 or DN150 flange. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, horn and installation accessory for measuring various liquids.

Radar water level sensor using advanced non-contact radar measurement technology has measuring range from 0-30m, 0-70m, optional output signal 4-20mA, HART, RS485/232 and optional power supply DC 12-24V, AC 220V. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, horn and installation accessory, can be used for measuring liquid level of reservoir/ river/ lake/ water tank.

Radar level sensor is a non-contact measurement for measuring various corrosive liquids. Measuring range from 0 to 10m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, and installation accessory.

Factory price radar level sensor is a non-contact measurement for measuring various highly corrosive liquids. Measuring range from 0 to 20m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, flange installation of DN50~DN200. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, and installation accessory.

Economical price radar level sensor is a non-contact measurement. Measuring range: power 0-12m or 0-15m, granules 0-18m, 0-20m, chunks 0-20m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, installation of G1-1/2"A thread or flange. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, horn and installation accessory for measuring various solids.

Radar level sensor is a non-contact solid measurement at factory price. Measuring range: power 0-10m, 0-20m or 0-35m, granules 0-12m, 0-25m or 0-40m, chunks 0-15m, 0-25m or 0-40m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, installation of DN80, DN100 or DN125 flange. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, horn and installation accessory for measuring various solids.

Low price radar level sensor is a non-contact solid measurement. Radar level transmitter consists of protection head with LCD display, waterproof connectors, internal radar antenna, and installation accessory for measuring various solids. Measuring range: powder 0-30m, 0-45m, granules 0-50m, chunks 0-50m, selectable output signal of 4-20mA, RS485 or 4-20mA+HART, power supply of DC 12-24V or AC 220V, flange installation, resolution 1mm.
