Portable Carbon Dioxide (CO2) Infrared Gas Detector, 0 to 2000/5000/10000 ppm

5 out of 5 based on 5 reviews | Write a review

$969.23

Portable carbon dioxide (CO2) infrared detector adopts high accuracy sensor, measuring range available with 0-2000ppm, 0-5000ppm, 0-10000ppm, or 0-10%VOL, 0-20%VOL, 0 to 100% VOL, with LCD display, audible, visual & vibrating alarm, compact size, easy to carry and operate.

Measuring Range *

Charger Plug *

Extension Probe *

Function

Data Logging [+$152.48]

Accessories

Calibration kit [+$175.35]

SKU: GD200-CO2

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview
Documents
Related Video

Portable pumping-suction CO₂ detector with alarming is suitable to monitor the concentration of carbon dioxide, in the incubator, center for disease control, agriculture planting, underground garage, laboratory, indoor air testing etc.

Features

LCD dot matrix display, direct readout of gas type, unit, concentration, local time, etc.
Support English/Chinese operation, easy to shift.
Gas concentration unit PPM and mg/m³can be shift quickly.
Built-in micro-sampling pump, 10 grades of suction are available.
Explosion-proof certification

Gas Detector Functions

With self-calibration and zero calibration functions, makes the detection more accurate and reliable.
One key to restore factory setting, free from maloperation.
With temperature and pressure compensation, able to realize the compensation for the gas concentration under different temperature and pressure environments.
Two-stage alarm with sound and light, and alarm point is settable.
Rechargeable lithiumpolymer battery with large capacity.
High-strength special engineering plastic housing, with anti-slip, waterproof, dustproof and explosion-proof.

Specification

Model	GD200-CO2
Sampling Method	Pump type, flow rate can be up to 750ml/min
Detection Principle	Infrared
Gas	Carbon Dioxide (CO2)
Range (Optional)*	0 to 1000/2000/5000/10000/20000/50000ppm; 0 to 10/20/25/30/50/100% VOL
Resolution	1 ppm (0-1000/2000/5000/10000/20000/50000ppm), 0.01% VOL (0-10/20/25/30/50/100% VOL)
Accuracy	≤±3% F.S.
Responce Time	≤10s
Repeatability	≤±1%
Recovery Time	≤10s
Linearity Error	≤±1%
Zero Shift	≤±1% (F.S./year)
Data Logging (Optional Function)	High speed data transmission by USB, available for data downloading and printing (The built-in IC card has about 2G memory, which can record 100,000 sets of data.)
Alarms	Sound, light and vibration
Display	LCD dot matrix display
Language	Chinese/English
Battery	3.7V rechargeable lithium battery, 3.7 Watt (Charger included: Input AC 100-240V 50/60Hz with optional USA, Europe or UK plug)
Operating Time	100h (Pump off)
Communication	Mini USB interface supports standard MODBUS communication protocol
Explosion-proof Grade	Ⅱ 2G Ex ia Ⅱ CT4 Ga
Case Material	ABS+PC
Protection Grade	IP66
Certification	CE, ATEX (Standard: EN IEC 60079-0:2018, EN 60079-1:2014)
Operating Temperature	-20℃~50℃
Operating Humidity	0~95%RH (non-condensing)
Operating Pressure	0.8~1.2bar
Dimension	2057532mm
Weight	300g
Warranty	12 months
Extension Probe	About 480mm (Total Length), About 300mm (Probe Head)
Accessories (Optional)	Calibration kit - gas pressure regulator (calibration gas cylinder NOT included) Body Material: Brass Max. Input Pressure: ≤15MPa Max. Output Pressure: 0.25MPa Flowmeter Range: 0.1-1.5 L/min Mounting Connection: Inlet port: W21.8-14; Outlet port: Ф6 flexible tube

Note:
* If you need a CO2 gas detector with other measuring ranges unlisted in above table, please contact us to inform your operating environment, so as to help you choose an appropriate one for your application.
* We also provide other common gas detectors, and you can refer to ATO Gas Detector Catalog to get the specific gas type and measurement range. If you have any questions, please feel free to contact us.

*** Other Common Gases and Ranges Available for Portable Gas Detectors

Gas Type	Measure Range	Resolution
Ammonia (NH3)	0-10/20/50/100/200/500/1000/2000/5000ppm	0.01ppm/0.1ppm/1ppm
Benzene (C6H6)	0-1/5/10/20/50/100/200/500/1000/2000/5000/10000ppm	0.001ppm/0.01ppm/0.1ppm/1ppm
Carbon Dioxide (CO2)	0-1000/2000/5000/10000/20000/50000ppm, 0-10%/20%/30%/50%/100% VOL	1ppm, 0.01% VOL
Carbon Monoxide (CO)	0-10/20/50/100/500/1000/2000ppm	0.001ppm/0.01ppm/1ppm
Chlorine (Cl2)	0-5/10/20/50/100/200ppm	0.001ppm/0.01ppm/0.1ppm
Chlorine Dioxide (ClO2)	0-1/5/10/20/50/100ppm	0.001ppm/0.01ppm/0.1ppm
Ethylene (C2H4)	0-10/20/50/100/500/1000/2000ppm	0.001ppm/0.01ppm/0.1ppm/1ppm
Flammable	0-100% LEL	1% LEL
Formaldehyde (CH2O)	0-10/20/50/100/500/1000ppm	0.01ppm/0.1ppm/1ppm
Hydrocarbons (HC)	0-100% LEL	1% LEL
Hydrogen (H2)	0-10/20/100/500/1000/2000/3000/5000/10000/20000/40000ppm, 0-4% VOL	0.001ppm/0.01ppm/0.1ppm/1ppm, 0.001% VOL
Hydrogen Chloride (HCl)	0-10/20/50/100/200/500/1000/2000ppm	0.01ppm/0.1ppm/1ppm
Hydrogen Cyanide (HCN)	0-10/20/50/100ppm	0.01ppm/0.1ppm
Hydrogen Fluoride (HF)	0-1/5/10/50ppm	0.001ppm/0.01ppm
Hydrogen Sulfide (H2S)	0-5/10/20/50/100/200/500/1000/2000ppm	0.001ppm/0.01ppm/0.1ppm/1ppm
Methane (CH4)	0-100% LEL, 0-50%/100% VOL	1% LEL, 0.01%VOL
Methyl Bromide (CH3Br)	0-50/100/200/500/1000/2000/3000ppm	0.1ppm/1ppm
Nitric Oxide (NO)	0-20/50/100/250/500/1000ppm	0.01ppm/0.1ppm/1ppm
Nitrogen (N2)	0-99.99%/100% VOL	0.01% VOL
Nitrogen Dioxide (NO2)	0-20/50/100/500/1000ppm	0.01ppm/0.1ppm/1ppm
Oxygen (O2)	0-25%/30%/100% VOL	0.01% VOL
Ozone (O3)	0-1/5/10/20/50/100/200/500/1000/2000ppm	0.001ppm/0.01ppm/0.1ppm/1ppm
Phosgene (COCl2)	0-1/5/10ppm	0.001ppm
Phosphine (PH3)	0-10/20/50/100/500/1000/2000/3000ppm	0.01ppm/0.1ppm/1ppm
Sulfur Dioxide (SO2)	0-20/50/100/500/1000ppm	0.01ppm/0.1ppm/1ppm
Sulfur Hexafluoride (SF6)	0-1000/2000/3000ppm	1ppm
Volatile Organic Compounds (VOC)	0-1/5/10/20/100ppm	0.01ppm/0.1ppm

Details

Carbon Dioxide Gas Detector Applications

Carbon Dioxide CO2 Gas Detector Applications

1. Carbon dioxide detector in animal husbandry
The quality of air is related to the healthy growth of animals. If the air is turbid for a long time, the concentration of carbon dioxide is high, and no ventilation is available, it will lead to animal disease or epidemic outbreaks. Therefore, a carbon dioxide detector is really necessary to keep measuring the concentration of CO₂, so as to prevent the occurrence of animal epidemics.

2. CO₂ gas detector in industry
Carbon dioxide (CO₂) detector is widely used in industry, such as waste water treatment, safe production, and especially in underground operation where it is very necessary to monitor the concentration of carbon dioxide. Carbon dioxide detectors are also widely applied in metal processing, pulp and paper making, cleaning and solvent extraction, cryogenic cleaning and other CO₂-related industries.

3. Carbon dioxide detector in public places
In crowded places, such as conference rooms, classrooms, exhibition halls, hospitals, shopping malls, bars, restaurants, airports, railway stations, entertainment halls, etc., carbon dioxide detectors can be installed for ventilation control and environmental quality monitoring, so as to protect people's health.

4. CO₂ gas detector in agriculture
Carbon dioxide is related to plant photosynthesis, so the CO₂ detector is widely used to monitor whether the concentration of carbon dioxide is enough. Appropriate concentration of gas fertilizer can increase the yield of agricultural crops. When carbon dioxide concentration is insufficient, gas fertilizer can be used, which is very helpful for crop growth and gain in crop yield.

Gas Detector Catalogue

ATO Gas Detector Catalog.pdf

Portable Gas Detector User Manual

ATO Gas Detector User Manual.pdf (Pumping Suction Type)

ATO Gas Detector Data Downloading Operation Instruction.pdf

ATO-GAS-S4 Gas Detector User Manual.pdf (Diffusion Type)

Communication Protocol

ATO Handheld Gas Detector Communication Protocol V1.0.pdf

Portable Gas Detector Calibration Accessories - Gas Pressure Regulator

ATO Single Stage Pressure Regulator User Manual

Gas Detector Software

ATO Portable Gas Detector DataExport Software

Basic Settings of Portable Gas Detector

This video will show you the basic settings of ATO portable gas detectors including high/low alarm setting, language setting and time setting.

Calibration of Portable Gas Detector

This video will show how to calibrate the ATO portable gas detectors.

Concentration Detection of Pesticides Gas
Methyl bromide is an organic compound with the chemical formula CH3Br, which is mainly used as a pesticide, fumigant, refrigerant and solvent, and can also be used in organic synthesis.This video will mainly use methyl bromide and CH3Br as examples to introduce the detection of their concentrations.

How to Detect Hydrogen Sulfide Concentration in the Toilet
Hydrogen sulfide is a flammable acidic gas that smells like rotten eggs at low concentrations and is very toxic. In actual operation, it is necessary to ensure that the detection equipment or method used can accurately measure the concentration of hydrogen sulfide, and pay attention to safety issues during operation to avoid hydrogen sulfide poisoning.

How much C2H4 (ethylene) do ripe bananas and apples produce?
We have various gas detectors such as: CO, O2, O3, H2, NH3, H2S, CH4, Cl2, CH2O, etc, from 0~10000ppm, Industrial or daily use.

Existing reviews of Portable Carbon Dioxide (CO2) Infrared Gas Detector, 0 to 2000/5000/10000 ppm

Do you have CO2 gas detector work in pressure from 0 to 200mbar？

Do you have a Portable Carbon Dioxide (CO2) Infrared Gas Detector, 0 to 2000ppm but works in pressure from 0 to 200mbar or to 500mbar?

From: peggy | Date: 25/07/2023

Was this review helpful? Yes No (0/0)

ATO Responded

Unfortunately, we have no suitable product recommendations.
Our gas detector cannot work in such a high-pressure environment.

Already used, great detector

During a power outage, the power supply in my house burned out, and I had to use a gas fireplace. The area that can be detected is very large. When carbon dioxide is detected, the device will beep and beep. Use this detector to let I am at ease.

From: Asher | Date: 19/04/2022

Was this review helpful? Yes No (0/0)

Can your portable gas detector work under (7-8 bar) pressure?

Can your portable gas detector work under (7-8 bar) pressure?

From: Janathan | Date: 12/12/2021

Was this review helpful? Yes No (0/0)

ATO Responded

No, it can not work properly, because the pressure is too high (7-8 bar), it can work only under pressure of 1 bar.

The gas detector I am looking for

So I am looking for a sensor that can sense nitrogen gas concentration in the system at an acceptable level. The N2 is being flooded into the system to help suppress oxygen and create a less combustible zone (it has been confirmed by a P. Eng that it is NOT an explosion rated situation). Other possible gasses include standard air and minute traces of ethanol (to the point that they may as well not be there). Gasses in the area are constantly evacuated by a fume scoop.

From: Yogaid | Date: 17/09/2021

Was this review helpful? Yes No (0/0)

ATO Responded

As per your described gas environment, our N2 Gas Detector: ATO-GAS-N2, 0 to 100% Vol will work effectively.

Carbon dioxide gas detector with data logging

For your carbon dioxide gas detector, has it the option to record measured values like a Data Logger and then transmit the recorded values to user's PC?

From: Butler | Date: 11/07/2019

Was this review helpful? Yes No (1/0)

ATO Responded

Yes, the CO2 gas detector has the optional function to record the measured values and transmit the data to PC by USB for downloading and printing.
