LCR Meter Price List
LCR meter is also called LCR bridge or LCR tester. It is a precision digital instrument for measuring Inductance (L), Capacitance (C), and Resistance (R) and other secondary specifications of electronic components. The secondary parameters include |Z|, |A|, X, B, G, D, Q, θd, θr, RDC, Vm, Im, △%, etc.
ATO provides the best LCR meters, both benchtop and handheld. A variety of test frequencies are available, up to 1MHz. Measurable inductance value up to 99.999kH, capacitance value up to 9.999F, and resistance value up to 99.9999 MΩ. Max measurement accuracy is up to 0.05%. Price of LCR meter is affordable, measurement speed is fast, function is complete, digital display is clear, and it is suitable for performance test of various electronic components.
Price List
| Product Name | SKU | Frequency Range | Accuracy | Test Specifications | Price |
| Handheld LCR Meter, 100Hz~100kHz | ATO-LCRM-1010 | 100Hz~10kHz | 0.2% | L, C, R, Z | $545.54 |
| 100Hz~100kHz | $707.08 | ||||
| Digital LCR Meter, 50Hz~100kHz | ATO-LCRM-5010 | 100Hz~10kHz | 0.2% | L-Q, C-D, R-Q, |Z|-Q | $594.92 |
| 50Hz~100kHz | 0.1% | |Z|, C, L, R, D, Q | $810.30 | ||
| Digital LCR Meter, 50Hz~200kHz | ATO-LCRM-5020 | 50Hz~200kHz | 0.05% | |Z|, |Y|, C, L, X, B, R, G, D, Q (deg), θ (Rad) | $1,444.46 |
| Digital LCR Meter, 20Hz~200kHz | ATO-LCRM-2020 | 50Hz~100kHz | 0.05% | L, C, R, |Z|, D, Q, |Y|, G, X, θd, θr, RDC, Vm, Im, △% | $1,552.15 |
| 50Hz-200kHz | $1,779.84 | ||||
| 20Hz-200kHz | $2,272.32 | ||||
| Digital LCR Meter, 20Hz~1MHz | ATO-LCRM-20100 | 20Hz~500kHz | 0.05% | |Z|, |Y|, C, L, X, B, R, G, D, Q, θ, DCR | $5,217.23 |
| 20Hz~1MHz | $6,601.85 |
LCR Meter Usage Steps
- Connect test line to LCR meter interface.
- Set specifications (frequency, level, current, C, L, R, X, B, R, G, D, |Z|, |Y|, etc.)、
- Clamp test fixture to DUT and start measuring.
Application
- Impedance measurement of semiconductor components such as capacitors, inductors, resistors, transformers, chip components and network components.
- Inductance and loss angle measurement of ferrites, magnetic cores, amorphous and other magnetic materials.
- Impedance measurement of printed circuit boards, relays, switches, cables, batteries, etc.
