Visible Spectrophotometer, Single Beam, 340/325-1000nm

5 out of 5 based on 1 reviews | Write a review

$1,320.71

Low price VIS spectrophotometer is designed for general quantitative analysis in visible region, with wavelength range 340-1000nm or 325-1000nm, high accuracy, good stability, easy operation and compact structure.

Wavelength Range *
Software *

SKU: ATO-VIS-721G

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview
Documents

Features

High-quality silicon photometric diode detector and 1200 lines/mm diffraction grating, to ensure high quality and high precision.
Backlit LCD display, easy for readout.
Precise automatic T/A changeover, and automatic adjustment 0A and 100%T.
Easy switching of transmittance, absorbance and concentration modes, just by pressing one key.
Direct concentration read-out and concentration factor setting function.
Easy to change the halogen lamp or deuterium lamp by the user.

Applications

Economic visible spectrophotometers are widely used in colleges and enterprises for general quantitative analysis and experiments based in absorbance measurements, such as medical and health, clinical testing, biochemistry, petrochemicals, environmental protection, quality control, and teaching labs.

Specification

Models	ATO-721G	ATO-722G
Optical System	Single beam, diffraction grating
Wavelength Range	340-1000 nm	325-1000 nm
Light Source	Tungsten halogen lamp 12V/20W
Receiving Component	Photocell
Wavelength Accuracy	±2nm
Wavelength Repeatability	≤1nm
Spectrum Bandwidth	5nm
Transmittance Accuracy	±0.5% (T) (NBS930D)
Transmittance Repeatability	≤0.2% (T)
Transmittance Measuring Range (T)	0.0%~100.0%
Absorbance Measuring Range (A)	0.000~1.999
Concentration Read-out Range	0000~1999
Stray Light	≤0.5% (T) (at 360nm, NaNO₂)
Drifting	≤0.5% (T)/3min
Signal Noise (T)	100% Noise≤0.3%, 0% Noise≤0.2%
Port	RS232
Cell Holder	50mm
Power Supply	220V 50Hz (Optional 110V 60Hz: pls tell us by email)
G.W.	13.5kg
Package Dimensions	560 x 480 x 290mm
Software	Optional

Note:
*Standard accessories: User manual 1pc + 1cm glass cuvette 4pcs + Power cable 1pc

Details

Tips: Maintaniance for Spectrophotometers

Spectrophotometers are precision instruments. Due to the working environment, operating methods and so on, its technical conditions will inevitably change in the operation, which may affect the performance of the instrument, and even cause the equipment failure. Therefore, analysts are able to detect and eliminate these hidden dangers in time, in order to ensure the normal operation of instruments and equipment.

If the test wavelength is changed significantly, wait for a moment until the lamp reaches heat balance, recalibrate the "0" and "100%" points and then measure again.
After using the cuvette, immediately rinse it with distilled water and wipe the water mark with clean soft gauze in case of the damage of surface which will affect the light transmittance of the cuvette.
The operator had better not move the light bulb and reflector lamp, so as not to affect the light efficiency.
After the amplifier sensitivity shifts, it must be re-zeroed.
Cuvettes should be assorted. The cuvette must be compatible used; otherwise it will make the test result meaningless.

• ATO Visible Spectrophotometer 721G 722G User Manual.pdf

• ATO UV VIS Spectrometer N4/N4S N2/N2S User Manual.pdf

Existing reviews of Visible Spectrophotometer, Single Beam, 340/325-1000nm

Visible spectrophotometer provides 4 cuvettes

We need a multi-cell holder: at least 2 cuvettes should be connected to the visible spectrophotometer?

From: Angie | Date: 04/03/2021

Was this review helpful? Yes No (0/0)

ATO Responded

Yes, we provide 4 of them.
Standard accessories: user manual 1pc+ 1cm glass cuvette 4pcs+ power cord 1pc.
