    Joystick Switch, 380V, 10A, 2/ 3 Knob

    5 out of 5 based on 1 reviews | Write a review
    $30.87
    Joystick switch with cheap price, features 380V AC rated voltage, 10A rated current, 30mm hole diameter, 2 knob/ 3 knob two product gear for selection. It is widely used in factory equipment, instrumentation, marine equipment, medical equipment, CNC lathes, and oil extraction.
    *
    SKU: ATO-JS-LS2
    This product has a minimum quantity of 3
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Cheap price joystick switch with 10-15A operating current, 100Ω insulation resistance, 0℃~85 ℃ Operating temperature. It has the advantages of strong shock resistance, convenient operation and long service life.

    Specification

    Model LS2-2 LS2-3
    Product gear 2 knob 3 knob
     Rated voltage 380VAC
    Rated current 10A
    Hole diameter 30mm
    Operating current 10-15A
    Insulation voltage 600V
    Insulation resistance 100MΩ
    Operating pressure 5-20N
    Contact resistance 200Ω
    Operating temperature 0℃~85 ℃
    Operation method Emergency
    Installation size 22mm
    Panel thickness 2-5mm
    Reset method Manual control
    Certificate CCC
    Warranty 12 months

    Dimension (mm)

     Dimension of joystick switch of LS2

    Tips: Classification of Joystick Switch.
    1. According to the use of contact elements.
    1) Snap-moving contact element.
    2) Driven contact element. The contact resetting methods are all non-automatic resetting.
    2. According to the protection method.
    1) Open type.
    2) Protected type.
    3. According to the type of non-automatic control actuator.
    1) Cross type handle;
    2) Rotary handle type;
    3) Handle type;
    4) Push button type;
    5) Foot pedal type;
    6) Button type
