0.001μF 630V Metal Film Capacitor

10nF Metal film capacitor adopts polypropylene film and aluminum foil inductorless winding, flame retardant epoxy powder encapsulation, good self-healing performance, lead pin is not easy to oxidation. 630V mylar capacitor is ideal for various high frequency and high current applications.

Specification

• Model: ATO-FC-CBB81-223JP20
• Capacity: 0.001μF
• Rated Voltage: 630V
• Tolerance: ±5%
• Lead Spacing: 7.5mm
• Installation Type: In-line type
• Dielectric Material: Polypropylene film
• Equivalent Series Resistance: 30000
• Operating Temperature: -40°C~105°C
• Dimension: 9.5 x 4.2 x 8mm
• Certificate: CE
• Weight: 0.0003kg

Features

• Metal capacitor has excellent insulation and flame retardant properties and low internal temperature rise.
• High voltage withstands, can reach the rated voltage above the voltage withstand, strong resistance to high current shock.
• Polypropylene film capacitors, under normal operating conditions, can reach more than ten years of service life.
• metallized polyester film capacitor is made of metallized polypropylene film with high temperature, and strong self-healing.
• ATO CBB22 metal film capacitor adopts a vacuum heat-setting process, which effectively excludes air and moisture, resulting in high insulation resistance and long-life of metal film capacitor.
• The 0.001μF film capacitors are epoxy resin coated according to UL-94V0 standard and the flame retardant level meets the stringent standards set by UL and IEC.

Applications

Diaphragm capacitors are widely used in high frequency, DC, and pulse circuits, suitable for color TV calibration circuits that require small size and excellent performance. ATO diaphragm capacitors are designed for S calibration circuits of large-screen displays and color TVs, and are suitable for various high-frequency and high-current applications.

Tips: Choose CBB22 or CBB8 metal film capacitor?

Is it better to choose CBB22 metal film capacitors, or should I choose CBB81 metal film capacitors? If it is an ordinary circuit, CBB22 capacitors are very cost-effective and the price is very cheap. You can directly use CBB22 capacitors, but if it is a high voltage, high frequency, In high-current circuits, the performance of CBB22 capacitors is not enough. CBB81 capacitors with better performance must be used. Its high-voltage and high-frequency performance is significantly better than that of CBB22 capacitors. In many high-power power supplies, CBB81 capacitors are used more, with better performance.
