4 hp Single Phase to 3 Phase Converter

5 out of 5 based on 1 reviews | Write a review

$3,145.59

Inexpensive 4 hp power converter, 3 kW, single phase to 3 phase, input & output frequency 50 Hz or 60 Hz, input 110V/ 220V/ 380V/ 415V/ 480V AC to output 220V/ 380V/ 440V/ 480V AC voltage can be customized, manufacturer direct sale.

Input Voltage (Single phase) *
Output Voltage (Three phase) *
Input Frequency *
Output Frequency *
Enclosure Type *

SKU: ATO-PHC-04

Qty:

30-day Returns

Delivery date: 6-12 days

Overview
Related Video
User Manual

The converter is high quality and safety, and its input voltage specification of the power converter ranges from 110V AC to 480V AC, its output voltage ranges from 220V AC to 480V AC, 4 hp single phase to there phase for sale, widely used in various power supply places with input & output frequency 50Hz/60 Hz.

Note:

When the load is a motor, the phase converter should be more than 5~7 times the motor capacity.
When the load is soft start + motor, the phase converter should be more than 3 times the motor capacity.
When the load is VFD + motor, the phase converter should be more than 1.5~2 times the motor capacity.

4 hp Converter Specification

Model		ATOBZT-3kW
Power		4 hp (3 kW)
Weight		85kg
Output Waveform		Standard pure sine wave
Wide Voltage Input		80-320V AC (can customization)
Input Voltage		Optional: 110V/ 120V/ 220V/ 230V/ 240V/ 380V/ 415V/ 440V/ 480V single phase 2 wire
Input Current		9.2A at 230V (Input Current=Power/Input Voltage/1.414)
Output Voltage		Optional: 220V/ 380V/ 400V/ 415V/ 440V/ 480V 3 phase 4 wire+PE
Output Current		4.3A at 400V
Input Frequency		50Hz/ 60Hz
Output Frequency		50Hz/ 60Hz
Startup Mode Selection		Stable frequency step-down start or frequency start, can be selected on the LCD screen settings
Frequency Stability		≤0.01%
Load Regulation		≤3%
THD		≤2% (Linear load)
Phase Angle		120^°±1^°
Crest Factor Ratio		3:1
Circuit Mode		IPM module, SVPWM modulation
LCD Display		Output voltage, output current, output frequency, output power, fault code, time temperature, startup mode selection, setting parameters
Protection		Input under voltage, overvoltage, output over-current, short circuit, overheating etc.
Protective Reaction Time		≤2ms
Machine Efficiency		≥94%
Insulation Properties		1800V AC/ 10mA/1 min
Insulation Impedance		500V DC/ 50MΩ
Cooling Method		Forced air cooling
Noise		1m> 60dB
Ambient Temperature		-25℃~+55℃
Humidity		0~95% (No condensation)
Size	L	450mm
	W	550mm
	H	760mm

Single Phase

Split phase

Details

4 hp Converter Features

In this video, ATO will show static phase converter converting single-phase 220V to three-phase 380V. And this phase converter has VFD technology to start the three-phase asynchronous motor to reduce the impact on the power grid.
