Buy a 0 to 30 psi pressure gauge online. It is a diaphragm pressure gauge with brass and stainless steel wetted parts for measuring water, oil, liquid and gas pressure, comes with a dual scale, 40mm dial diameter, stainless steel, 1/8" BSPT thread specification for connection, pressure measurer is mainly used in metallurgy, electric power, petroleum, chemical industry, etc.
Specifications
- Model: ATO-TS-Y408-30psi
- Dial Diameter: φ40mm
- Installation Method: Radial
- Range: 0~30 psi, 0~2 bar
- Installation Diameter: 1/8
- Thread Specification: BSPT
- Size: 6x4x2.5cm
- Material: Stainless Steel
- Package Size: 8.5x6.5x4.5cm
- Product Weight: 44g
- Package Weight: 60g
Features
- 0 to 30 psi pressure gauge can be used as a water pressure gauge, air pressure gauge, hydraulic pressure gauge and oil pressure gauge.
- ATO pressure gauge equipped with dual scale (0~15 psi/0~1 bar), and a lower-mount male connection with a 1/8" BSPT thread.
- The circular dial is enclosed in a stainless steel case for corrosion resistance, portable 0~1 bar pressure gauge offers clear readings and is weather-resistant.
- Display accuracy of 2.5% over the entire range of the gauge.
- Brass and stainless steel wetted parts for measuring non-corrosive liquid and gas pressure. Such as water, oil, fuel, coolant, air, co2, nitrogen, and argon pressure test.
Dimension (Unit: mm)
Details
Applications
Pressure gauge is the most commonly used measuring instrument for displaying and controlling pressure, widely used in the chemical industry, petroleum, metallurgy, mining, and electric power production, especially in vehicle maintenance shops, heat pipe networks, water and gas supply systems, etc.
Tips: How does a pressure gauge work?
The pressure gauge transmits the pressure deformation to the pointer through the elastic deformation of the sensitive components (Bourdon tube, diaphragm box, bellows) in the watch, and then the conversion mechanism of the watch movement, causing the pointer to rotate to display the pressure. This is the working principle of a pressure gauge.
