Beam Load Cell, 200kg/500kg/1000kg/3 ton/5 ton to 10 ton

$119.96

SKU: ATO-LC-B02

Cantilever beam load cell has two ends, one end for fixing, one end for loading, with sealed well, high accuracy, easy to install, easy to use, good interchangeability. It can bear both tension and pressure, and has good automatic self-aligning performance after force. Load cell can be applied for ultrathin electronic truck scale, platform scales, hopper weigher and other weighing instruments.

Cantilever Beam Load Cell, 500kg/1000kg/2 ton/3 ton/5 ton

$150.79

SKU: ATO-LC-B03

Cantilever beam load cell is a six-wire strain gauge tension and compression load cell with high accuracy and low price. Beam load cell has the standard size and fits to replace the same load cells of the mixing plant. ATO cantilever beam load cells are available for weight or force measurement from 500kg/1000kg/2 ton/3 ton to 5ton.

Shear Beam Load Cell for Rail Weighbridge/Truck Scale, 10/20/30/50 ton

$489.42

SKU: ATO-LC-SB01

Shear beam load cell has a combined indenter for automatic resetting and self-aligning, with strong anti-eccentric load capability and easy installation. Shear beam load cell is suitable for rail weighbridge, truck scale and various electronic scales.

Shear Beam Load Cell, 1 ton/2 ton/5 ton/10 ton/20 ton to 30 ton

$357.14

SKU: ATO-LC-SB02

Shear beam load cell can bear both tension and pressure, with high accuracy, easy to install, easy to use. Strain gauge load cell can has customizable working temperature 200℃ (392℉). Shear beam load cell can be applied for vehicle-specific scales, bridge crane scales, vehicle wheel force or axial force measurement.

3 Axis Load Cell 50N/100N/200N/500N/1000N/2000N to 5000N

$1,337.57

SKU: ATO-LC-MA02

3 axis load cell is a multi axis load cell for force measurement of X/Y/Z axis. Three axis load cell has 0.5%FS accuracy, IP66 protection class, good anti-eccentric load performance and 12 months long operating life. It can be applied for precise control of the robotic arm, surface grinding and polishing, CNC high precision carving and precision testing of medical equipment.

Load Cell Transmitter, Output 0-5V/0-10V/4-20mA

$81.27

SKU: ATO-LCTR-OA

Load cell transmitter is made of aluminum alloy, output standard signal 0-5V/0-10V/4-20mA, has linear compensation, humidity compensation, external zero debugging, external span debugging, input overload protection and output short circuit protection functions.

Digital Load Cell Amplifier, Output 4-20mA/0-10V/RS485

$109.85

SKU: ATO-LCTR-OAR

High precision load cell amplifier has a 6 digit LED display, output signal 4-20mA/ 0-5V/ 0-10V/ RS485. There are 3 keys for parameter settings. Digital load cell amplifier can be calibrated on-line by its 3 keys. The setting parameters include zero, capacity, communication rate, division value, decimal digits, etc.

Load Cell Junction Box for Scales, 2/3/4/6/8/10 Inlets to 1 Outlet

$66.67

SKU: ATO-LCBOX-10I

Multi-channel load cell junction box has 2/3/4/6/8/10 inlets and 1 outlet, aluminum alloy casing, good anti-interference, special for waterproof sealing joint, waterproof and dustproof rubber gasket for cover, easy to assemble and debug. Each channel can be adjusted balance to prevent damage to the sensor caused by inductive lightning and surge signals.

3 Axis Load Cell, 5kg/10kg/20kg/30kg to 100kg

$907.33

SKU: ATO-LC-MA3A

High performance 3-axis load cell sensor, multi axis load cell to measure force in X, Y and Z axes. Suitable for different load ranges from 5kg, 10kg, 20kg, 30kg to 100kg, small size for easy installation, accurate and reliable multi-dimensional force test to ensure accurate force measurement.

2 Axis Load Cell, 50kg/100kg/200kg/500kg to 1000kg

$438.57

SKU: ATO-LC-MA2A

High precision 2-axis load cell sensor for sale, can be customized with different load ratings, range 50kg, 100kg, 200kg, 500kg, 1000kg optional, high accuracy, widely used in industrial automation and testing field to meet various needs. Stable and reliable, ideal for your weighing solution.

Piezoelectric Force Sensor, 0 to 30000N

$691.19

SKU: ATO-PFS-30KN

Purchase piezoelectric force sensor at factory price. This piezoelectric load cell with 0 to 30000N measuring range, measures force by converting mechanical stress into an electrical charge through the piezoelectric effect, which is commonly used in applications requiring precise force measurements, such as in industrial automation, robotics, and quality control.

Earth Pressure Cell with Data Collector, Vibrating Wire

$201.54

SKU: ATO-LC-RSZX

Vibrating wire earth pressure cell is equipped with a high-precision vibration wire data collector to monitor the pressure on the rock and soil during the construction process. The optional ranges are 0-0.2 MPa, 0-0.4 MPa, 0-0.6 MPa, 0-0.8 MPa, and 0-1.0 MPa, covering a wide range of pressure measurement needs. Temperature sensors can be added to monitor real-time changes in environmental temperature.

Load cell is actually a kind of device to transform the weight/force signal into the measurable electrical signal output. In general, it can connect to a special digital panel meter to obtain readings directly, or connect to a load cell transmitter/amplifier to output standard signal (0~5V, 0~10V, 0~±10V, 4~20mA, or RS485). At present, the most common load cell is the resistance strain gauge load cell, which utilizes the principle that the resistance modifies accordingly when the resistance strain sheet deforms. Load cell is mainly constituted by four parts, which are respectively the elastic component, resistance strain gauge, measuring circuit and transmission cable. The load cells mainly include several types, such as single point load cell, S type load cell, button load cell, column typeload cell, low profile load cell, beam load cell, shear beam load cell and multi axis load cell.
