    30 W DC Gear Motor, 3000 rpm, 12V/24V

    30 W DC Gear Motor, 3000 rpm, 12V/24V

    5 out of 5 based on 4 reviews | Write a review
    $127.94
    12V/24V DC gear motor for sale at low price, 3-phase 30W brushless electric DC motor features 3000 rpm rated speed, 0.1 Nm rated torque, combines with parallel shaft gearbox able to reduce speed while cranking out a high output torque up to 3 Nm. 3:1 to 200:1 gear ratio are available.
    *
    *
    *
    *
    SKU: ATO-BLDC-30
    30-day Returns
    Free Shipping
    Delivery date: 20-30 days

    A DC gear motor is an electric motor that converts DC electrical energy into mechanical energy. It combines the characteristics of a DC motor and a gearbox to provide precise speed and position control, as well as high torque output. The 24V model shown in the video is shown in more detail using a brushless DC motor controller (12V ~ 30V).

    30W DC gear motor provides high torque at low speed in an economical solution for industrial applications. Brushless DC motor has 3000 rpm rated speed and 3.31A rated current at 12V, 1.56A at 24V voltage. Buy the gear motor and matching controller can support speed regulation, and clockwise and counterclockwise rotation.

    30W DC gear motor specifications

    Model ATO-D2BLD30-12 ATO-D2BLD30-24
    Power 30W
    Weight 1.5 Kg
    Voltage 12V 24V
    Rated Speed 3000 rpm 3000 rpm
    No-load Speed 3300 rpm 3300 rpm
    Rated Current 3.13A 1.56A
    Rated Torque 0.1 N.m 0.1 N.m
    Peak Torque 0.29 N.m 0.29 N.m
    No-load Current < 0.6A < 0.4A
    Compatible controller Model BLD-120A (Click it to the product page)
    Protection Grade IP54
    Motor Lead Length 300mm
    Temperature 0~50℃
    Gearbox Model 2GN□K, Enter the gear ratio into the box (□) within the model name
    Gear Ratio 3, 5, 7.5, 10, 12.5, 15, 18, 20, 25, 30, 36, 40, 50, 60, 75, 90, 100, 120, 150, 180, 200

    Note: Motor length, power, voltage and speed can be customized according to your requirements under the allowed circumstance of adoptable dimension.

    The allowable torque with a gearbox

    Gear Ratio 3 5 7.5 10 12.5 15 18 20 25 30 36 40 50 60 75 90 100 120 150 180
    Speed (r/min) 1000 600 400 300 240 200 167 150 120 100 83.33 75 60 50 40 33 30 25 20 17
    Allowable Torque (N.m) 0.23 0.39 0.58 0.74 0.97 1.16 1.39 1.39 1.74 2.09 2.51 2.8 3 3 3 3 3 3 3 3
    Allowable Torque (kgf.cm) 2.32 3.87 5.8 7.73 9.67 11.6 13.92 13.94 17.43 20.91 25.1 27.89 30 30 30 30 30 30 30 30

    Note:

    • The values colored "Red" indicate that the gear head and the DC motor are running in the same direction, and the other values are in the opposite direction.
    • When it is desired to reduce the speed further than the gear ratio in the table above, an intermediate speed reducer with a gear ratio of 10 can be installed between the motor and the gearbox.

    Wiring Definition

    30W DC motor wiring explanation

    Dimension (Unit: mm)

    30W DC Motor Dimension:30w gear motor dimension

    Gearbox Dimension:

    30W gearbox dimension

    L1=41.5mm

    Details

    30W DC Gear Motor Details

    Tips: Why installation site of DC gear motor is important?

    DC gear motor is based on ordinary DC motor and added a matching gearbox. The gearbox is installed mainly to reduce the speed of gear motor, thus improving the torque. Different gearboxes provide different speeds and torques for the gear motors. The installation site of DC geared motor is very important. Why?

    1. Different installation sites means different assembly processes for the gear motor.
    2. The ventilating valve shall be set at different places for different installation sites.
    3. Wrong installation site leads to wrong lubricating oil dosage, thus causing leakage, bearing wear, noise or overheated.
    4. The DC gear motor mainly adopts the splash lubrication, different installation sites require different lubricating oil.
