Features
- Universal AC input range selectable by a switch
- Protections: short circuit, overload and overvoltage
- Cooling by free air convection
- LED indicator for power on
- 100% full load burn-in test
- Low cost and high reliability
Specification
Model |
ATO-S-200-48 |
Output
|
DC Voltage |
48V |
Rated Current |
4.2A |
Current Range |
0 ~ 4.2A |
Rated Power |
200W |
Ripple & Noise (Max.)(Note 2) |
100mVp-p |
Voltage Adjust Range |
43 ~ 53V |
Voltage Tolerance (Note 3) |
±1.0% |
Line Regulation |
±0.5% |
Load Regulation |
±0.5% |
Setup, Rise, Holdup Time |
100ms, 50ms, 20ms at full load |
Input |
Voltage Range |
88 ~ 132VAC/176V~264VAC (selected by a switch) or 255 ~ 370VDC |
Frequency Range |
47~63Hz |
Efficiency (Typ.) |
87% |
AC Current (Typ.) |
3.2A/115V AC 1.6A/230V AC |
Inrush Current (Typ.) |
Cold start: 35A |
Leakage Current |
<3.5mA/240V AC |
Protection |
Overload |
105~150% rated output power Protection type: Shut down output voltage, re-power on to recover. |
Overvoltage |
55.2~64.8V Protection type: Shut down output voltage, re-power on to recover. |
Environment |
Working Temperature |
-10 ~ +60℃ |
Working Humidity |
20~90% RH non-condensing |
Storage Temperature |
-20~+85℃ |
Storage Humidity |
10~95% RH non-condensing |
Temperature Coefficient |
±0.03%/℃ (0~50℃) |
Vibration |
10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes |
Safety & EMC (Note 4) |
Safety Standards |
UL1012 Approved |
Withstand Voltage |
I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC |
Isolation Resistance |
I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/70% RH |
EMC Emission |
Compliance to FCC Part 15 J conduction Class B |
EMC Immunity |
Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, light industry level, criteria A |
Others |
MTBF |
≥286.7K hrs MIN. MIL-HDBK-217F (25℃) |
Dimension |
199*110*50mm (L*W*H) |
Weight |
0.8kg |
Note |
1. All parameters NOT specially mentioned are measured at 230V AC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance includes set up tolerance, line regulation and load regulation. 4. The switching power supply is considered a component which will be installed into final equipment. Please make sure that the final equipment still meets EMC directives. |
Dimensions (Unit: mm)
Details
SMPS Power Supply Applications
- Power Tools
Electric Saw, Drilling Machine, Ginder, Sand Blast Machine, Puching Machine, Weeding Machine, Air Compressor, etc.
- Offices Devices
Computer, Printer, LCD Monitor, Scanning Machine, etc.
- Electrics & Household Appliance
TV, VCRS, Radio, Dust Collector, Fan Lamp or LED Strip, Sewing Machine, Microwave Oven, Fridge/Freezr, Coffemarker, etc.
- Industrial Equipemnt
Monitoring Equipment, Shipping, Vehicle, Metalhalide Lamp, Solar System, Wind Power Generation, etc.
Tips: How to lower ripple nose of switching power supply (SMPS)?
1. Strengthen the inductor and filtering of output capacitor
According to a formula about the switching power supply, current fluctuation in the inductor forms up an inverse relationship with the inductance. In addition, output ripples constitute inverse relationship with capacitance. Increase of inductance and output capacitance can reduce ripples, but this measure just plays a minor role.
2. Secondary smoothing means adding another LC filter
LC filter performs well in inhibiting noise ripples. To reduce ripples of SMPS power supply, users shall select appropriate inductors and capacitors to form up a filter circuit according to frequency of ripples to be removed.
3. Connect switching power supply output to LDO filter
It serves as an effective way to reduce the SMPS ripples and noises. This method can help users maintain a constant voltage without changing original feedback system, but it brings about highest costs and energy consumption.
4. Connect capacitor C or RC to diode in parallel
Values of capacitor C or RC connected to the diode in parallel can be determined only by repeated experiments. If the values are set in a false way, it may cause serious oscillating.
5. Diode post inductance (EMI filter)
It is a common way to curb high-frequency noise of the switching power supply. Users need to select appropriate inductors according to frequency of noise. This method can effectively inhibit noise, but it shall be noticed that the rated current of inductors must comply with actual demands.
