    4 inch Flanged Y Strainer

    $538.92
    High quality 4" (DN100) flanged strainer, y type, is used in piping systems to remove unwanted particles, debris, and other impurities from fluid flowing through the system. PN16 working pressure, SS 304 or 316 for selection, stainless steel materials can withstand high temperatures and pressure.
    *
    SKU: ATO-FYS-100
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Buy a 4 inch (DN100) stainless steel flanged strainer online. With PN16 working pressure, SS 304/316 material, the Y-type filter is widely used in the chemical industry, heating, refrigeration, petroleum, construction, wind power, etc.

    Specifications

    • Model: ATO-GL41H
    • Type: Y Type Strainer
    • Nominal Diameter: 4 inch (DN100)
    • Working Pressure: PN16
    • Product Material: 304/316 Stainless Steel
    • Connection Form: Flange
    • Temperature Range: -40°C~180°C
    • Weight: 16.5kg

    Dimensions (Unit: mm)

    Stainless steel Y strainer dimension

    Main Part Materials
    NO. Part Name Materials QTY
    1 BODY CF8/CF8M 1
    2 FILTER S304/S316 1
    3 JOINT GASKET PTRE/RPTFE 1
    4 CAP CF8/CF8M 1
    5 BOLT OUTER HEXAGON S304 4-12



    DN b L±1.05 D D1 D2 T f z-φd
    100 100 322 220 180 156 22 2 8-φ18


    Applications

    Y-type strainers can remove impurities, debris, and solid particles from fluid or gas pipelines in industrial and commercial applications. They are typically used in applications where a high flow rate is required, and where there is a risk of damage to equipment or processes from the presence of solid particles.

    Stainless steel Y strainer applications

    Tips: Why use a Y strainer instead of other types of strainers?

    A Y strainer is often preferred over other types due to its compact design and efficient debris removal capabilities. The Y shape allows for a relatively low-profile installation in pipelines, making it suitable for applications with space constraints. Its angled straining element effectively captures solid particles, preventing their entry into downstream equipment. Y strainers are particularly advantageous in situations where periodic maintenance for cleaning is acceptable. Compared to basket strainers, Y-type strainers are easier to clean and typically result in less pressure drop. The simplicity of their design and ease of installation, often facilitated by flanged connections, contribute to their popularity in industries such as petrochemical, water treatment, and HVAC, where protecting equipment from debris is crucial for maintaining system efficiency.
