    G3/4" Pneumatic Shuttle Valve

    $77.89
    Low price G3/4 inch pneumatic shuttle valve is a type of valve used in pneumatic systems to control the flow of compressed air. It allows air to flow from one inlet to either of two outlets, depending on the position of a shuttle mechanism inside the valve.
    SKU: ATO-PSV-ST06
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Pneumatic shuttle valves are commonly used in applications where it's necessary to switch between two pneumatic circuits or devices using a single control signal. They can be found in various industrial applications, such as automated manufacturing processes, pneumatic control systems, and robotics.

    Specification

    • Model: ATO-ST-06
    • Working Medium: Air
    • Effective Sectional Area: 110mm2
    • Joint Pipe Port: G3/4 inch
    • Working Pressure Range: 0~0.8MPa
    • Operating Temperature Range: 0~60℃

    Dimension (Unit: mm)

    Pneumatic shuttle valve dimension

    Model A B C D E F G
    ATO-ST-06 110 72 40 7 70 58 G3/4"

    Tips: How to troubleshoot common issues with pneumatic shuttle valves?

    To troubleshoot common issues with pneumatic shuttle valves, start by checking for air leaks, as they can compromise the valve's function. Ensure proper installation and connection of tubing, and inspect for any damage or blockages. Verify that the shuttle valve is correctly aligned and not jammed. If the valve fails to switch between ports, assess the actuation mechanism for wear or misalignment. Confirm that air pressure is within the specified range and that the supply is clean and dry. Additionally, inspect seals and O-rings for damage and replace if necessary. If problems persist, consult the manufacturer's documentation for specific troubleshooting steps or consider seeking professional assistance. Regular maintenance and adherence to manufacturer guidelines are crucial for optimal pneumatic shuttle valve performance.
