    150A 100V 15000W Variable DC Power Supply

    $5,317.69
    150A 100V variable DC power supply is a reliable power source, catering to the energy needs of testing, prototyping, and energizing electronic circuits. Operating in a switching mode, it delivers a robust 15000W DC output, selectable single phase 110V, three phase 220V or 380V±10% AC input, 3-digit LED display, offering flexibility for different power sources.
    *
    SKU: ATO-VDCPS100150K
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Variable DC power supply rated at 150 amp and 100 volt serves as a dependable and adjustable power source for a wide range of applications. This adjustable DC power supply offers flexibility and reliability, making it an ideal choice for diverse electronic projects. With its adjustable voltage and current capabilities, coupled with advanced digital control features, this power supply demonstrates efficiency and dependability.

    Specification

    Model ATO-JK100150K
    Input Voltage Single Phase 110V AC, Three Phase 220V or 380V AC (+/- 10%)
    (240V, 400V, 415V, 440V, 460V 480V can be customized)
    Output Voltage Range 0-100V
    Output Current Range 0-150A
    Output Power 15000W
    Frequency 50Hz/60Hz
    Adjustable Mode Pulse Width Modulation (PWM) Type
    Transistor Connection Method Full Bridge
    Output Type Dual
    Display 3 digit
    Display Accuracy Output Voltage ±0.5%, Output Current ±0.5%
    Efficiency >86%
    Load Regulation (CV) Stable Voltage ≤0.5%, Constant Current ≤0.5%
    Line Regulation (CV) Stable Voltage ≤0.5%
    Ripple Voltage ≤1%
    Insulation Resistance Input-Output: ≥20MΩ
    Input-Chassis: ≥20MΩ
    Output-Chassis:≥80MΩ
    Dielectric Strength Input-Output: AC1500V, 10mA, 1 minute
    Input-Chassis: AC1500V, 10mA, 1 minute
    Output-Chassis: AC1500V, 10mA, 1 minute
    Protection Over Load and Over Voltage Protection
    Current Imbalance ≤5% + 0.5A
    Operating Ambient -10℃ to + 45℃/ 85%RH
    Storage Ambient -10℃ to + 80℃/ 80%RH
    Overheat Protection Ambient Threshold 70℃ to 80℃
    Mean Time Between Failures ≥50000h
    Cooling Duct Internal Cooling Air Duct Forward and Exit
    Certification CE, RoSH
    Warranty 12 Months
    Size 700 (L) x 480 (W) x 295 (H) mm
    Weight 45kg


    Detail

    Details of 150A 100V Adjustable DC Power Supply

    Tips: Can a variable DC power supply be used for testing and repairing electronic devices?

    Yes, a variable DC power supply is an essential tool for testing and repairing electronic devices. It provides a controlled and adjustable voltage output, allowing technicians to simulate different power conditions. This is crucial for identifying and troubleshooting issues in electronic circuits, as components often require specific voltage levels to function correctly. The ability to vary voltage and current settings helps in assessing the stability and performance of devices under different operating conditions. Additionally, it enables the isolation of faulty components by supplying power incrementally and monitoring for abnormalities. In summary, a variable DC power supply is a versatile and indispensable instrument for electronics professionals, offering precision and control in the diagnostic and repair processes.
