1 inch Swing Check Valve, DN25, CPVC

5 out of 5 based on 2 reviews | Write a review

$180.11

Factory price 25mm swing type check valve uses CPVC for chemical resistance, corrosion resistance and high-temperature resistance. 1 inch swing check valve is typically used in piping applications where reliable backflow prevention is required, such as water supply, wastewater treatment, irrigation and industrial processes.

Flange Implementation Standard *

SKU: ATO-SCV-001

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview
Documents

Buy a 1 inch swing check valve at a low price. DN25, strong heat resistance & chemical resistance, low maintenance. Longlife CPVC swing type check valve can prevent backflow and ensure unidirectional flow in the piping system, perfect for chemical processing plants, water treatment facilities, etc.

Features

The check valve can prevent the phenomenon of liquid counter-current from protecting the pump equipment.
Because it is a cantilever check valve, there is less resistance to flow.
The 1 inch swing check valve uses CPVC materials and plays a strong corrosion resistance to prevent acid and alkali fluid.
Not only can the valve body be removed from the pipeline, but also the valve cover can be opened for internal inspection and maintenance.

Specifications

Model: ATO-H44F-10S
Check Valve Type: Swing
Nominal Diameter: 1 inch/25mm
Nominal Pressure: 16kg
Drive Mode: Manual
Pressure Environment: Low Pressure
Type (Channel Position): 2 Ways
Flow Direction: One Way
Body Material: CPVC
Connection Form: Flange
Weight: 1.85kg
Applicable Medium: Acid-Base concentration higher than 30%, lower than 60%, except hydrochloric acid.

Dimension (Unit: mm)

Swing check valve dimension

Nominal Diameter	D1	D2
Nominal Diameter	D1	GB	JIS	ANSI
DN25	115	85	90	3.13
L	h	n-Φ
L	h	GB	JIS	ANSI
160	18	4-Φ14	4-Φ19	4-Φ16

Applications

Swing check valve applications

Tips: What is a swing check valve?

A swing check valve is a type of valve used to control the flow of fluid in a pipeline. It is also commonly referred to as a "tilting disc check valve" or simply a "check valve."

The valve consists of a hinged disc or flap that swings open to allow fluid to flow through the valve and swings closed to prevent backflow. When the pressure on the inlet side of the valve is greater than the pressure on the outlet side, the disc swings open, allowing the fluid to pass through the valve. When the pressure on the outlet side is greater than the pressure on the inlet side, the disc swings shut, preventing backflow.

Swing check valves are commonly used in applications where backflow prevention is critical, such as in water and sewage treatment plants, irrigation systems, and industrial processes. They are available in a range of sizes, materials, and configurations to suit different applications and installation requirements.

ATO Stainless Steel Swing Check Valve Datasheet

ATO CPVC Swing Check Valve Datasheet

ATO Stainless Steel Wafer Check Valve Datasheet

ATO Foot Check Valve Datasheet
